What is the Deep Cycle Gel battery?

Table of Contents


Deep Cycle Gel battery utilizes gel technology and combine latest AGM excellent process , componsed of strong grids, high purity lead and  fumed silica Gel electrolyte with good cycle life and wide temperature range performance. The unique plate design and patented structure design provides the good frequent cyclic discharge performance

Gel batteries are called gel because they use silica (or sand) to turn the acid inside the battery into a thick liquid. This liquid does make it spill-proof, like our AGM batteries, but the gel is fragile, and can be easily burned if used in high amperage situations. Things like quick charging, high discharge, or other intense situations are all likely to cause serious damage to a gel battery, making it fail even if it’s barely used.

deep-cycle gel batteries are sealed, maintenance-free batteries that deliver superior power in demanding renewable energy applications. Engineered for rugged durability, outstanding performance and long battery life, deep-cycle gel batteries feature a number of important design characteristics that provide significant advantages over competing gel products. The gelled electrolyte is a proprietary formulation that delivers consistent performance and dramatically extends the battery’s cycle life. Lead alloy grids provide longer shelf life and superior corrosion resistance as well as deliver more concentrated energy to the terminals. Its premium grade, double-insulated separators allow maximum charge flow between the plates for optimum performance.


· Specifically designed for Solar and energy storage applications
· Use multiple rare-earth alloy of independent intellectual property right and special lead paste formulations
· Usage of imported low -resistant raw materials and advanced process
· Deep cycle design with patented nanometer level gel electrolyte

Gel Battery Performance


Gel batteries have low rate capacity (C20 to C3), as for AGM batteries if the design is comparable. Very long discharge rates, e.g., C120 for solar application, are possible due to the large electrolyte reserve. High rate discharge capacity can be smaller when compared with AGM technology due to limitation of plate distance and the resistance of the cell.

The self-discharge, especially in the absence of phosphoric acid, is very low: initially, the capacity loss is <0.1% day−1 and, after 2 years of storage, <30% (e.g., for a 100 Ah battery).

Gel batteries can be deep discharged, i.e., discharged below the specified cutoff voltage in extreme cases or down to zero volt, which will lead to a small capacity loss only after recharge.

Endurance in Cycling

Gel batteries achieve a cycle life up to 1000 cycles with 75% depth of discharge depending on design, especially of the positive plate (tubular or grid plate), the electrolyte composition, and the cycling regime. Gel batteries are robust against variations in the charging regime and the state of charge, making them very suitable for all types of outdoor cycling and solar applications.

Float Service Life (Stationary Applications)

Gel batteries with positive tubular plates achieve a proven service life in stationary applications of more than 15 years. At high temperatures, the behavior is excellent and the negative impact of high temperatures on high rate discharges is small as compared with AGM batteries.

Gel cell batteries fill a wide range of uses including marine, RV, Solar and UPS/Telecom. Whether you need a gel battery for a marine application, or an ATV or motorcycle battery you’ll find the best prices and the best battery solutions. Contact Brava if you have questions or need help finding the best battery marine for your boat or watercraft.

  • 30 to 55 Ah Gel Cell Batteries for Water Applications
  • 56 to 100 Ah Gel Batteries | Marine & Boat Applications
  • 101 Ah & Up Gel Batteries for Your Marine Applications

For which applications can I use a gel battery?

Gel batteries are extremely versatile and suitable for a wide range of applications. You can use them as:

  • Batteries for Marine Applications
  • Batteries for Infrastructure
  • Batteries for the rehabilitation industry
  • Batteries for robotica
  • Batteries for motorhomes, caravans and commercial vehicles
  • Batteries for electric transport
  • Batteries for energy storage systems

Tips: more detail information,for Lead acid gel battery.
