DRY CHARGED/MF STARTER Battery Series

Brava The first main product is car battery with dry charged and MF series, which is mainly used for car, truck, taxi, bus, ship, marine starting , etc…
The Second main product is VRLA-AGM battery with FM and GFM series, which is main used for UPS/EPS, Electricity & Communication System, Solar &Wind Energy Storage System, Railway, Aerospace and navigation, Military area
etc…

AGM90(DIN88) CAR BATTERY

Reliable and High Performance

1)The battery consists of high-performance paste plate,low resistance separators, high-impact resistant polypropylene plastic tank .
2)Stable performance in different temperature working environment..Low internal resistance and high starting ,
3)Tight assembly, PP/PE separator is provided for your choice, and reduces batteries resistance and corrosion inside for their own character.
4)Durable and strong material with well design constructers, it has good ventilation function and good anti-explosive character Provide greater vibration resistance.
5)Customer-made special dimension available(even provide brand&packaging design),OEM
6)Maintenance free calcium-calcium construction Long designing

32C24R start-stop battery

Model: S32C24R


Voltage : 12v
CCA : 350A
Rated Capacity : 40Ah@20hr
Reserve Capacity : 57Ah@20hr
Size : 237 x 127 x 200 x 220mm
Weight : 11.02kg
Terminal : A
Warranty: 3 Year Warranty

36B20R start-stop battery

Model: S36B20R



Voltage : 12v
CCA :
320A
Rated Capacity : 35Ah@20hr
Reserve Capacity : 52Ah@20hr
Size : 197 x 128 x 202 x 227mm
Weight : 9.88kg
Terminal : B
Warranty: 3 Year Warranty

DRY CHARGED STARTER Battery Series – JIS Starter Lead Acid Car Battery

New Type Standard JIS Voltage Capacity at 20HR Rate 5HR CCA at-18°C
/ NS40 12 32 25.6 160
36B20R NS40Z 12 36 28 175
32C24R N40 12 40 32 200
46B24R NS60 12 45 36 225
48D26R N50 12 50 40 250
55D26R N50Z 12 60 48 300
/ NS70 12 65 52 325
80D26R NX110-5 12 68 54.4 340
65D31R N70 12 70 56 350
75D31R N70Z 12 75 60 375
95D31R NX120-7 12 80 65 400
/ N90 12 90 72 450
/ NS100 12 95 16 475
95E41R N100 12 100 80 500
115F51 N120 12 120 96 550
135G51 N120 12 120 108 600
145G51 N150 12 150 120 650
/ N160 12 160 132 680
180H52 N180 12 180 144 800
190H51 N200 12 200 160 900
/ 6TN 12 100 80 500

MF STARTER Battery Series – JIS Starter Lead Acid Car Battery

New Type Voltage Capacity at 20HR Rate 5HR RC (MIN) CCA at-18°C
MFNS40 12 32 25.6 47 256
MFNS40Z 12 36 28.8 59 280
MFN40 12 40 32 69 320
MFNS60 12 45 36 79 360
MFN50 12 50 40 89 400
MFN50Z 12 60 48 109 480
MFNS70 12 65 52 120 520
MFNX110-5 12 68 55 125 544
MFN70 12 70 56 132 560
MFN70Z 12 75 60 139 600
MFNX120-7 12 80 64 151 640
MFN100 12 100 80 195 800
MFS31 12 / / 256 900
MFN120 12 120 239 860
MFN135 12 135 258 860
MFN150 12 150 308 960
MFN165 12 165 326 900
MFN180 12 180 378 1100
MFN200 12 200 426 1200
6TN 12 100 195 800

DRY CHARGED STARTER Battery Series – DIN Starter Lead Acid Car Battery

DIN TypeCapacity at
20HR Rate
CCA ICECCA ENRCLayoutTerminalHold Down
DIN363618025259031
DIN44442203087101B03
DIN45452253157901BO3
DIN55552753859901B03
DIN606030042010901B03
DIN666633046212201B03
DIN707035049013201B03
DIN757537552513901B03
DIN808040056015101B03
DIN888844061616901B03
DIN10010050070019501B03

MF STARTER Battery Series – DIN Starter Lead Acid Car Battery

DIN Type Voltage Capacity at
20HR Rate
RC CCA
at-18°C
MFDIN36 12 36 59 280
MFDIN44 12 44 7 352
MFDIN45 12 45 79 360
MFDIN55 12 55 99 440
MFDIN60 12 60 109 480
MFDIN66 12 66 122 528
MFDIN70 12 70 132 560
MFDIN75 12 75 139 600
MFDIN80 12 80 151 640
MFDIN88 12 88 169 700
MFDIN100 12 100 195 800
AGM90(DIN88) CAR BATTERY

9 Typical Applications

  • Stand-alone solar systems
  • Solar lighting systems
  • Telecommunication equipment
  • Electronic instruments
  • Fire alarm
  • Security devices
  • UPS power supply
  • Emergency lighting
  • Various industrial applications
car

Start-Stop Battery For CAR

AGM50-105, EFB50-105 Series Battery
pickup trucks

Start-Stop Battery For Pickup

32B20R-65D26R
truck

Start-Stop Battery For Truck

65D31R-95D31R
Motorcycles

Start-Stop Battery For Motorcycles

12V3.5-9.0A
Forklift

Start-Stop Battery For Forklift

36V480-1105A
marine boat

Start-Stop Battery For Marine/RV

27M-700

FAQ

1. How long do deep cycle batteries last?

The average lifespan of a deep cycle battery is about 3-6 years. However, the lifespan of a deep cycle battery will vary based on several factors such as the type of battery, how it is used and maintained, and the climate in which it is kept.

2. Can I connect batteries in series and in parallel?


Yes, you can. The maximum number that can be connected in parallel is 4. In series, there are no limitations.


3. Can I connect a 100 Ah battery to a 200 Ah battery?


No, you can’t. All the batteries you connect together should be the same capacity (Ah), the same voltage (V), and most importantly, the same battery type (AGM). And it would be better if they come from the same brand.


4. What’s the best way to place and store this battery?


It’s a sealed battery and we recommend placing the battery upright. It is allowed to be placed and installed on its side only if there are special reasons for doing so. DO NOT place the battery upside down. You should store it in a dry and cool (5°F~104°F / -15°C~40°C) place. Make sure that it is 100% charged before storing it, and recharge after three months.


5. Can I discharge the battery to 0% and then recharge it again?


To avoid cycle life shortening, it is recommended not to discharge the battery below 50%. And when not in use, we recommend charging it 100% before storing it and recharging it after three months.


6. I will go to live in my forest cabin during the winter holiday. So I want to know that can this battery be used at freezing temperatures?


The discharge working temperature range is 5°F~122°F (-15°C~50°C) and the charge temperature range is 5°F~104°F (-15°C~40°C). Using this battery at a lower or higher temperature than the range will shorten the battery’s lifespan. We recommend checking the specific daily temperature of the place you will be going before using this AGM battery.


7. When using a charge controller, which battery type should I set?


You should choose the SLD battery settings.


8. What factors affect the lifespan of a deep cycle battery?

There are many factors that affect the lifespan of a battery. The most important factors are:

• AGM technology(Price)
• The temperature
• Frequency of Cycle
